Model | Power | Hmax | Flow | Voltage | Size | Outlet Size | Ilet Size |
DYH-15D | 15W | 5m | 1200L/h |
12-24V
|
84×47×60mm | φ10mm | φ14mm |
Precautions:
1. The user must check whether the rated voltage on the nameplate of the water system is consistent with the actual voltage before using the pump.
2. This source can only be used in fresh water or sea water, not in any other liquid.
3. Do not work this pump in water above 35°C or below the freezing point, otherwise it will cause damage to the source.
4. The water pump cable cannot be replaced. If the power cable is damaged during use, it must not be used.
5. When installing or removing and cleaning the water pump, you must first pull out the plug and cut off the power supply to ensure safety.
6. The maximum diving depth of the submersible pump is 1 meter.
1. The user must check whether the rated voltage on the nameplate of the water system is consistent with the actual voltage before using the pump.
2. This source can only be used in fresh water or sea water, not in any other liquid.
3. Do not work this pump in water above 35°C or below the freezing point, otherwise it will cause damage to the source.
4. The water pump cable cannot be replaced. If the power cable is damaged during use, it must not be used.
5. When installing or removing and cleaning the water pump, you must first pull out the plug and cut off the power supply to ensure safety.
6. The maximum diving depth of the submersible pump is 1 meter.
